R1-T08

EM-T87X Rugged Tablet PC

Features

·Front 5.0MP + Rear 13.0MP, autofocus with flashlight
·Symmetric speakers. More immersive, more clear
·User-friendly buttons designed for efficient action

Performance

·Android 12/GMS OS and 8GB RAM＋128GB storage
·8 inch IPS screen, 1920×1200 TFT, 550nits
·5-point capacitive touch

Communication

·Upgrade BT 5.2, fast and more stable
·High speed 4G LTE and dual-band Wi-Fi 5
·Optional high performance 2D imager designed to data capture

Reliability

·Enhanced rugged corners withstand shock and impact
·IP65 Waterproof and Dustproof, MIL-STD-810H certified
·Removable 10000mAh battery & New battery-free working mode

Product Six views

Specifications Parameter

Basic parameters
Dimension	236.7 x 155.7 x 20mm
Weight	device unit 910g
Device Color	black
LCD	8 inch TFT 16:10, 1920×1200, 550nits
Touch Panel	5 point capacitive touch screen
Camera	Front 5.0MP Rear 13.0MP
I/O	USB 2.0 Type-A x 1, SIM Card, TF Card (Three in one card holder), USB Type-C x 1, 12pins Pogo Pin x 1, Φ3.5mm standard earphone jack x 1
Power	USB Type-C interface, supports fast charging PE+2.0, maximum power of 18W, maximum 9V/2A
Performance parameter
CPU	ARM (OCTA Core)
OS	Android 12/GMS
RAM	8GB
Storage	128GB

Battery
Capacity	10000mAh/3.8V
Type	Removable Li-polymer battery
Endurance	9hrs ( 50% volume sounds, 50% screen brightness, 1080P HD video display by default )
Network connections
WIFI	802.11 a/b/g/n/ac (2.4G/5.8G)
Bluetooth	BT5.2 Transmission distance: 10m
4G	LTE FDD: B1/B2/B3/B4/B5/B7/B8/B17/B20/B28A/B28B， WCDMA: B1/B2/B5/B8，GSM: B2/B3/B5/B8，LTE-TDD: B38/B39/B40/B41
GNSS	Support, GPS, Glonass
Reliability
Operate Temperature	-20 °C ~ 60 °C
Store Temperature	-30 °C ~ 70 °C
Humidity	95% Non-Condensing
Rugged Feature	IP65 certiﬁed, MIL-STD-810H certiﬁed
Drop Height	1.22m drop
Data Collection
2D	Optional
NFC	13.56MHz, Support ISO/IEC 14443A/B/15693/18092/mifare protocol Card reading distance: 4cm
